Bird's Eye View
Close Up View
Click on an image to open a larger version in another window.
Remove existing roofing to bare wood sheathing and dispose of properly. Install 30 squares of standing-seam metal, formed on site into 16-inch panels using factory-enameled roll steel; double-lock all seams. Use custom brake-bent flashing from same material for drip edge and all flashing at roof-wall intersections. Assume a 5-square hip roof; custom flashing at two average-sized skylights; and custom cap treatment at vented ridge. Apply over new felt underlayment; use ice-and-water membrane at eaves, valleys, and all penetrations.
Click to save or download a 3-D SketchUp model for the roofing replacement.
Important: To view and work with this model, you need to have Google SketchUp software loaded. For a free download, click here.
All projects in SketchUp created by MC DesignBuild, Inc.
