Bird's Eye View
Close Up View
Click on an image to open a larger version in another window.
Remove existing roofing to bare wood sheathing and dispose of properly. Install 30 squares of 235-pound fiberglass asphalt shingles (min. 25-year warranty) with new felt underlayment, galvanized drip edge, and mill-finish aluminum flashing. Assume a 5-square hip roof; custom flashing at two average-sized skylights; and custom cap treatment at vented ridge.
Click to save or download a 3-D SketchUp model for the roofing replacement.
Important: To view and work with this model, you need to have Google SketchUp software loaded. For a free download, click here.
All projects in SketchUp created by MC DesignBuild, Inc.
